Features:



General Specifications:



Name : AMD Ryzen 5 3400G with Radeon RX Vega 11 Graphics



Family : Ryzen



Series : Ryzen 3000 Series



Form Factor : Desktops, Boxed Processor



Market Segment : Mainstream Desktop



AMD PRO Technologies : No



Regional Availability : Global , China , NA , EMEA , APJ , LATAM



Former Codename : Picasso



Processor Architecture : Zen+



# of CPU Cores : 4



Multithreading (SMT) : Yes



# of Threads : 8



Max. Boost Clock : Up to 4.2 GHz



Base Clock : 3.7 GHz



L1 Cache : 384 KB



L2 Cache : 2 MB



L3 Cache : 4 MB



Default TDP : 65W



AMD Configurable TDP (cTDP) : 45-65W



Processor Technology for CPU Cores : 12nm FinFET



CPU Compute Die (CCD) Size : 210mm²



Package Die Count : 1



Total Transistor Count : 4.94 Billion



Unlocked for Overclocking : Yes



CPU Socket : AM4



Supporting Chipsets : X570 , X470 , X370 , B450 , B350 , A320



CPU Boost Technology : Precision Boost 2



Instruction Set: x86-64



Supported Extensions : AES , AMD-V , AVX , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64



Thermal Solution (PIB) : AMD Wraith Spire



Thermal Solution (MPK) : AMD Wraith Spire



Max. Operating Temperature (Tjmax) : 95°C



*OS Support:

Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit



Connectivity:



Native USB 3.2 Gen 2 (10Gbps) : 0



Native USB 3.2 Gen 1 (5Gbps) : 4



Native USB 2.0 (480Mbps) : 0



Native SATA Ports : 0



PCI Express® Version : PCIe® 3.0



Native PCIe® Lanes (Total/Usable) : 20 , 16



Additional Usable PCIe Lanes from Motherboard : X470

2x Gen 3, 8x Gen 2



NVMe Support : Boot , RAID0 , RAID1 , RAID10



System Memory Type : DDR4



Memory Channels : 2

Max. Memory : 64 GB

System Memory Subtype : UDIMM

Max Memory Speed :



2x1R

DDR4-2933

2x2R

DDR4-2667

4x1R

DDR4-2133

4x2R

DDR4-1866

ECC Support : Yes (Requires mobo support)



Graphics Capabilities:



Graphics Model : Radeon RX Vega 11 Graphics



Graphics Core Count : 11

Total Graphics Shaders : 704



Graphics Frequency : 1400 MHz



GPU Max. Memory : 2 GB



WDDM Version : 2.7



DirectX Version : 12



OpenGL : 4.6



OpenCL :2.2



DisplayPort Version : 1.4a



DisplayPort Extensions : Adaptive-Sync , HBR3 , HDR Metadata



DisplayPort Max Refresh Rates (SDR):

3840×2160 @ 60Hz , 3440×1440 @ 144Hz , 2560×1440 @ 180Hz , 1920×1080 @ 240Hz



DisplayPort Max Refresh Rates (HDR):

3840×2160 @ 60Hz , 3440×1440 @ 60Hz , 2560×1440 @ 60Hz , 1920×1080 @ 120Hz



HDMI Version : 2.0



HDCP Version Supported : 2.2



USB Type-C DisplayPort Alternate Mode : Yes



Multi-Monitor Support : Yes



Max Displays : 3



AMD FreeSync™ : Yes



AMD Eyefinity Single Large Surface (SLS): No



Wireless Display : Miracast



Max Video Encode Bandwidth (SDR) :



1080p205 8bpc H.264, 1440p115 8bpc H.264, 2160p51 8bpc H.264, 1080p205 8bpc H.265, 1440p115 8bpc H.265, 2160p51 8bpc H.265



Max Video Decode Bandwidth:



1080p60 MPEG2, 1080p60 VC1, 1080p240 8bpc VP9, 1080p240 10bpc VP9, 1080p240 H.264, 1080p240 8bpc H.265, 1080p240 10bpc H.265, 1080p240 JPEG 8bpc



Warranty:3 Years
